Use of a mule shoe has, however, several inherent disadvantages, such as: To complete the connection can be difficult and some axial force is usually necessary to complete the operation and fulfil the required intention. As a result the sub often needs an additional force, by means of a hydraulic pressure, to ensure that it locks into position.

Mule (shoe) - Wikipedia

If the shoe or the matching shape is worn or meet tip to tip, a jam may occur and the unit becomes stuck or may act falsely as connected to the body - if using the mule shoe for orientation of directional drilling tools with an independently rotating internal drive shaft, a locking mechanism or coupling between the drive shaft and the outer body of the drill is needed in order to obtain a reference point.

This locking coupling is sensitive to malfunctioning and will usually be very difficult to operate when the hole gets deep, due to high torque. Moreover, it is difficult to know if the locking device or coupling is in open or closed mode. It is therefore a need for an orientation system that does not need the current mule shoe. Moreover it is a need for an orientation system that can sense the position of a point on the outer body of a device with respect to gravity, independent of the position of the point on the peripheral surface of the outer body at any time.

Moreover, it is also a need for a system that does not depend on a locking mechanism or coupling between the drive shaft and the outer body of a device being a drill or other tools with an independently running internal drive shaft. It is also a need for a orientation system comprising a survey unit that can be removed and brought to surface when orientating tools or bodies that do not require continuous orientation, such as stationary tools, like a wedges or a valves etc. Moreover, its also need for a system that can be brought to surface for downloading data, i.

Such determinations or calculations may be real-time activities or logged for later downloads, on surface or downhole, and if desired, used for adjustment of the position of the device. The adjustment may be automatic, semi-automatic or manual. According to this principle, a reference point member may be arranged on an outer element for example an external body or part of a structure, the well bore, a tube, casing or the like, while detectors or devices sensing the position of the reference point member and gravity are positioned on the device whose position are being identified.

The term "outer element" should be understood to also comprise the situation where the reference point member is arranged on an outer body of the device, and the detectors are arranged internally, for example associated with an inner element arranged inside the device. In both cases, the detectors sense outwards. It should be appreciated, however, that the reference point member and the detectors may be configured in such way that the detectors sense inwards, i.

In the drawings and the detailed description of an embodiment below, only the embodiment having the reference point member arranged on an outer body of the device and detectors arranged on or associated with an inner element, preferably retractable from the outer body, are shown and described, without thereby intending to limit the invention and scope of protection to such embodiment. Also the embodiments comprising a solution where the detectors are arranged on an outer element such as an outer ring surrounding a centrally arranged reference point member is intended to be encompassed by the scope of protection.

An object of the present invention is to provide a system that can provide the same degree of flexibility as the mule shoe, i. An object of the invention is also to obtain a system that can be used for obtaining information of the orientation of a core sample. Another object of the present invention is to provide an alternative way of determining the position of a device, moveably or stationary arranged in a well bore.


  • !
  • Julia Child's unbelievable Texas connection: French cooking came armadillo close to a makeover!
  • .

It should be appreciated that another object of the invention is to provide a system that may be used in connection with orientation of multiple types of downhole tools and systems, including but not limited to any type of drilling system, rod orientation, packers, wedges, valves, branches, monitoring and controlling systems.

Another object of the present invention is to provide a system and a method improving the identification or monitoring of the position of a device moving through or stationary in a bore or hole, such as a drill string or a tool, by determining the position of a reference point member on the device relative to gravity. It should be appreciated that the system does not depend on a locking mechanism or coupling between the drive shaft and the body of the device if used on for example a drill with an independently running internal drive shaft.

Moreover the sensing devices and electronics can be removed and brought to surface, leaving only the relatively low cost reference point member downhole. Yet another object of the invention is to provide a orientation system giving good readings close to vertical, something that is known to be a problem for existing systems based on moveable weights, balls and similar to determine the low side of the device. It should also be appreciated that the orientation system according to the invention may in certain cases be seated permanently. The objects are achieved by means of a system and a method as further defined by the independent claims, while embodiments, variants and alternatives are defined by the dependent claims.

According to the present invention a system for identifying or monitoring the orientation and position of a device, such as a tool is provided. The system is intended to be moved through or be stationary arranged in a medium, such as rock, and comprises an orientation unit comprising an outer element and an inner element. The inner element may be retrievable. The system further comprises:.

The data may also be used to calculate the inclination of the device or orientation of a core sample. The first and second detectors are preferably arranged on another element of the orientation unit than the reference point member. According to one embodiment of the system, the fixed reference point member may be mechanically or physically fixed on the outer element, while said at least one first and at least one second detector are arranged on the inner element.

In a preferred embodiment, the outer element is the outer body of the device. According to a second embodiment of the invention, the fixed reference point member may be fixed on a body centrally arranged on the device whose position should be identified, while said at least one first and at least one second detector is arranged on a ring or tube surrounding the centrally arranged fixed referenced point member arranged inside the device.

The reference point member may comprise at least one magnet, the first detector may comprise at least one magnetic field detector, preferably. By "magnet" it is in this application meant permanent magnets, electro magnets or magnetic fields made in any other way. In this application, whenever the word "magnet" is written it should be interpreted as a permanent magnet, electro magnet or a magnetic field made in any other way.

Moreover, the reference point member may be placed in fixed seat s on the outer body of the device, intended to create an artificial magnetic field that can be detected by the first detector. The inner element may comprise a separate rotatable alignment shaft, and a magnet may be fixed to the rotatable shaft, said magnet will always align with the reference point member on the outer element, as said reference point member comprises one or more magnets. Thus the alignment shaft will rotate due to the magnetic forces, and independently of the inner element.

In another embodiment magnets are not fixed to the alignment shaft, but the alignment shaft itself is magnetic, and will rotate to align with the reference point magnets. It should be appreciated that at least one magnet may be fixed to the end of the rotatable alignment shaft, providing a magnetic field that is sensed by a magnetic field detector such as a magnetometer or hall effect sensor, allowing the detector to sense the shaft orientation.

Based on the position of the shaft, the position of the reference point member will be given. Moreover, the reference point member may be chosen from one of a radioactive source, laser, permanent magnet, electromagnet and Radio Frequency Identification RFID. In one embodiment, the entire tool is made non-magnetic, allowing a magnetometer also to read directions relative to magnetic north. The magnetometer may be the first detector, or another separate detector. The present invention also relates to a method for identifying or monitoring the orientation and position of a device, such as a tool.

The method relates to a system, intended to be moved through or left stationary in a medium, such as rock, and comprises an orientation unit comprising an outer element and an inner element. The inner element is preferably retrievable. The method comprises the following steps:. According to one embodiment of the invention, the method comprises fixing the reference point member mechanically or physically to the outer element, while arranging said at least one first and at least one second detector on the retrievable inner element. According to another embodiment, the method comprises fixing the reference point member on a body centrally arranged on the device while arranging said at least one first and at least one second detector on a retrievable outer ring.

The method may comprise arranging one or more magnets to a rotatable alignment shaft, in the inner element of the orientation unit, allowing at least one of said magnet to align with a magnet on the outer element acting as reference point member, by rotating the alignment shaft, and arranging a magnet on an end of said alignment shaft, and using the magnetic field from it as a source for monitoring and identifying the position and orientation of the alignment shaft.

By using the data from the magnetic field detector and a gravitation detector, such as an accelerometer or inclinometer the position of the reference point member may be determined relative to gravity. Moreover, the method may also comprise determining or calculating real-time activities or data can be logged for later downloads, on surface or downhole. Gravitation detectors, such as accelerometers or inclinometers are used together with any one of the detectors for sensing the rotational position of the outer element, and thus the position for the device may be identified.

Moreover, it should also be appreciated that the system according to the present invention is to provide an improved orientation system that can replace the current use of a mule shoe, and when operating a system with internal drive shaft that rotates independently of the tool body, it is not necessary nor required to include a locking device for aligning the mule shoe shed in a known position relative to the outer body. According to the present invention, the detector for identifying the rotational position of the alignment shaft, when aligned with the reference point member, may in lieu of a magnet field detector, be provided at the circumference of the free end of the alignment shaft with a number of separated axially orientated sectors, co- functioning with brushes or shoes, similar to the system used on the commutator on an electric motor, the position of the various sectors with respect to the position of the corresponding magnet on the alignment shaft being known.

In the following principles and an embodiment of the invention shall be described in further detail, referring to the drawings wherein:. Figure 1 discloses schematically one principle for a orientation unit according to the present invention, indicating a suitable position of an embodiment forming the reference point member and the configuration of the first and second detector;.

Figure 2 discloses schematically and in principle for a orientation unit using a second embodiment of the invention, showing the device forming the reference point member, the detectors applied and a second one or more magnets fixed to a rotatable alignment shaft;. Figure 3 shows schematically a directional core drill with the orientation unit according to the present invention for identifying or monitoring the orientation and position of a the drill;. Figure 4 shows mud motor drill unit, with the orientation unit according to the present invention for identifying or monitoring the orientation and position of the unit.

Figure 5 shows schematically a part of the interior of a drilling system, with the orientation unit according to the invention;. Figure 6 shows schematically a retrievable orientation unit in accordance to the invention. Description of the Reference Signs. The following description of the exemplary embodiments refers to the accompanying drawings. The same reference numbers in different drawings identify the same or similar elements.

The following detailed description is not meant or intended to limit the invention. Instead, the scope of the invention is defined by the appended claims.

Moreover, the embodiments to be discussed next are not limited to these configurations, but may be extended to other arrangements as discussed later. Reference throughout the specification to "one embodiment" or "an. Thus, the appearance of the phrases "in one embodiment" or "in an embodiment" in various places throughout the specification is not necessarily referring to the same embodiment.

Further, the particular features, structures or characteristics may be combined in any suitable manner in one or more embodiments. Figure 1 discloses schematically a orientation unit showing the principle used according to one embodiment of the present invention, indicating a suitable position of the magnet forming the reference point member 13 and the configuration of the first and second detector 15, The Figure indicates schematically a orientation unit 10 provided with an outer element 1 1 and a inner element 12 arranged inside the outer element 1 1.

The orientation unit 10 constitutes as a separate but yet integral part of the drilling tool and is arranged downhole together with the tool. According to the element shown, a reference point member in form of a magnet 13 is arranged in a fixed position on the outer element 1 1 , providing a magnetic field.

The outer element 1 1 may have a cylindrical cross sectional shape, having a centreline A magnetic field detector such as a magnetometer or a halleffect sensor 15 may be incorporated in the inner element 12 and is preferably centrically positioned with respect to the inner element The magnetic field detector 15 may be of any known type measuring the magnetic field of the magnet 13 arranged on the outer element 1 1 , and hence the circumferential position of the magnet The system according to the embodiment shown in Figure 1 , functions in the following way:.

The information from the detectors may either be processed and used in real time downhole or communicated to the surface, or may be saved and processed when the inner element 12 is retrieved to the surface.
