Targeting rotor sites with ablation did not stop reentries in the homogeneously remodelled atria independent from lesion size mm radius , from linearly connecting lesions with anatomical obstacles, and from the number of rotors targeted sequentially up to 3. Our results show that phase maps derived from intracardiac electrograms can be a powerful tool to map atrial activation patterns, yet they can also be misleading due to inaccurate localization of rotor tips depending on electrode resolution and distance to the wall.
This should be considered to avoid ablating regions that are in fact free of rotor sources of AF. In our experience, ablation of rotor sites was not successful to stop fibrillation. Our comprehensive simulation framework provides the means to holistically benchmark ablation strategies in silico under consideration of all steps invol. This study hypothesized that P-wave morphology and timing under left atrial appendage LAA pacing change characteristically immediately upon anterior mitral line AML block.
Perimitral flutter commonly occurs following ablation of atrial fibrillation and can be cured by an AML. However, confirmation of bidirectional block can be challenging, especially in severely fibrotic atria. Furthermore, an initial negative P-wave portion in the inferior leads was observed, which was attenuated in case of additional cavotricuspid isthmus ablation.
V1 jump and V1 delay are novel real-time electrocardiography criteria allowing fast and straightforward assessment of AML block during ablation for perimitral flutter. During atrial fibrillation, heterogeneities and anisotropies result in a chaotic propagation of the depolarization wavefront. The electrophysiological parameter called conduction velocity CV influences the propagation pattern over the atrium. We present a method that determines the regional CV for deformed catheter shapes, which result due to the catheter movement and changing wall contact.
The algorithm selects stable catheter positions, finds the local activation times LAT , considers the wall contact and calculates all CV estimates within the area covered by the catheter. The method is evaluated with simulated data and then applied to four clinical data sets. Both sinus rhythm activity as well as depolarization wavefronts initiated by stimulation are analyzed.
A speed of 0. For clinical cases, the CV magnitude range of 0. The P2P amplitude of 0.
Synonyms and antonyms of Solution in the German dictionary of synonyms
The correlation of 0. In this paper, a method is presented and validated which calculates the CV for the deformed catheter and changing wall contact. Different levels of mental workload were induced by a secondary task n-back task with three levels of difficulty.
Subjective data showed a significant increase of the experienced workload over all three levels. An exploratory approach was chosen to extract a large number of rhythmical and morphological features from the ECG signal thereby identifying those which differentiated best between the levels of mental workload.
No single rhythmical or morphological feature was able to differentiate between all three levels. A group of parameters were extracted which were at least able to discriminate between two levels. For future research, a combination of features is recommended to achieve best diagnosticity for different levels of mental workload. Heart rate variability HRV plays an important role in medicine and psychology because it is used to quantify imbalances of the autonomic nervous system ANS.
This is a controlled phenomenon that leads to a synchronized coupling between respiration and instantaneous heart rate. Thus, the portion of HRV that is not related to respiration, and could potentially contain undiscovered diagnostic value, is overlapped and remains hidden in a standard HRV analysis. In such cases, a decoupling procedure would deliver a discriminated HRV analysis and possible new insights about the regulation of the cardiovascular system. In this work, we propose an algorithm based on Granger's causality to measure coupling between respiration and HRV.
In the case of significant coupling, we estimate and cancel the respiration driven HRV component using a linear filtering approach. We tested the method using synthetic signals and prove it to deliver a reliable coupling measurement in Afterwards, we applied our method to signals recorded during paced respiration and during natural breathing.
We demonstrated that coupling is dependent on respiratory frequency and that it maximizes at 0. Furthermore, the HRV parameters measured during paced respiration tend to level among subjects after decoupling. The intersubject variability of HRV parameter is also decreased after the separation process.
During natural breathing, coupling is notoriously lower to non-existing and decoupling has little impact on HRV. We conclude that the method proposed here can be used to investigate the diagnostic value of respiration independent HRV parameters. The most important ECG marker for the diagnosis of ischemia or infarction is a change in the ST segment. Baseline wander is a typical artifact that corrupts the recorded ECG and can hinder the correct diagnosis of such diseases. For the purpose of finding the best suited filter for the removal of baseline wander, the ground truth about the ST change prior to the corrupting artifact and the subsequent filtering process is needed.
In order to create the desired reference, we used a large simulation study that allowed us to represent the ischemic heart at a multiscale level from the cardiac myocyte to the surface ECG. We also created a realistic model of baseline wander to evaluate five filtering techniques commonly used in literature.
In the simulation study, we included a total of 5. We found that the best performing method was the wavelet-based baseline cancellation. However, for medical applications, the Butterworth high-pass filter is the better choice because it is computationally cheap and almost as accurate.
Even though all methods modify the ST segment up to some extent, they were all proved to be better than leaving baseline wander unfiltered. Radiofrequency ablation has become a first-line approach for curative therapy of many cardiac arrhythmias. Various existing catheter designs provide high spatial resolution to identify the best spot for performing ablation and to assess lesion formation.
However, creation of transmural and nonconducting ablation lesions requires usage of catheters with larger electrodes and improved thermal conductivity, leading to reduced spatial sensitivity. As trade-off, an ablation catheter with integrated mini electrodes was introduced. The additional diagnostic benefit of this catheter is still not clear.
In order to solve this issue, we implemented a computational setup with different ablation scenarios. Our in silico results show that peak-to-peak amplitudes of unipolar electrograms from mini electrodes are more suitable to differentiate ablated and nonablated tissue compared to electrograms from the distal ablation electrode. However, in orthogonal mapping position, no significant difference was observed between distal electrode and mini electrodes electrograms in the ablation scenarios.
In conclusion, catheters with mini electrodes bring about additional benefit to distinguish ablated tissue from nonablated tissue in parallel position with high spatial resolution. It is feasible to detect conduction gaps in linear lesions with this catheter by evaluating electrogram data from mini electrodes. In den Lebenswissenschaften ist die Individualisierte Medizin aktuell ein zentrales Thema, vielleicht ein Hype.
Individualisierte Medizin, das ist eine gute Botschaft, betont sie doch die Wertigkeit des einzelnen Patienten. Die Behandlung dieser Gebiete bedarf einer separaten nachfolgenden Betrachtung. Eine der Aufgaben der Akademien ist es, Ordnung in die vorhandenen Aussagen und auch damit vorhandene Daten zu bringen, die in unterschiedlichen Disziplinen hervorgebracht werden, um daraus ein Gesamtbild zu formen. Wichtige Grenzen der wissenschaftlichen Politik- bzw. Das setzt eine Selbstbegrenzung voraus. Das bedarf immer einer gegenseitigen kritischen Begleitung. Die Wissenschaft dient dem Erkenntnisgewinn.
Wenn dieses angenommen, akzeptiert werden kann, dann sind die Technikwissenschaften Wissenschaften, dann betreiben Radiologie und Nuklearmedizin Wissenschaft science. Wissenschaft wird von Menschen betrieben und getragen. Bildgebung in Klinik und Forschung: Beitrag zur Individualisierten Medizin?
Electrocardiographic imaging ECGI has recently gained attention as a viable diagnostic tool for reconstructing cardiac electrical activity in normal hearts as well as in cardiac arrhythmias. However, progress has been limited by the lack of both standards and unbiased comparisons of approaches and techniques across the community, as well as the consequent difficulty of effective collaboration across research groups..
To address these limitations, we created the Consortium for Electrocardiographic Imaging CEI , with the objective of facilitating collaboration across the research community in ECGI and creating standards for comparisons and reproducibility. Both EDGAR and the workgroups will facilitate the sharing of ideas, data and methods across the ECGI community and thus address the current lack of reproducibility, broad collaboration, and unbiased comparisons. Robust and exact automatic P wave detection and delineation in the electrocardiogram ECG is still an interesting but challenging research topic.
The early prognosis of cardiac afflictions such as atrial fibrillation and the response of a patient to a given treatment is believed to improve if the P wave is carefully analyzed during sinus rhythm. Manual annotation of the signals is a tedious and subjective task. Its correctness depends on the experience of the annotator, quality of the signal, and ECG lead. In this work, we present a wavelet-based algorithm to detect and delineate P waves in individual ECG leads. We evaluated a large group of commonly used wavelets and frequency bands wavelet levels and introduced a special phase free wavelet transformation.
The local extrema of the transformed signals are directly related to the delineating points of the P wave. First, the algorithm was studied using synthetic signals. Then, the optimal parameter configuration was found using intracardiac electrograms and surface ECGs measured simultaneously. The reverse biorthogonal wavelet 3. In the end, the method was validated using the QT database from PhysioNet.
We showed that the algorithm works more accurately and more robustly than other methods presented in literature. The validation study delivered an average delineation error of the P wave onset of In conclusion, the algorithm is suitable for handling varying P wave shapes and low signal-to-noise ratios.
Computational models of cardiac electrophysiology provided insights into arrhythmogenesis and paved the way toward tailored therapies in the last years. To fully leverage in silico models in future research, these models need to be adapted to reflect pathologies, genetic alterations, or pharmacological effects, however. A common approach is to leave the structure of established models unaltered and estimate the values of a set of parameters. Today's high-throughput patch clamp data acquisition methods require robust, unsupervised algorithms that estimate parameters both accurately and reliably.
In this work, two classes of optimization approaches are evaluated: Using synthetic input data and different ion current formulations from the Courtemanche et al. Sequential combination of the two algorithms did improve the performance to some extent but not satisfactorily. Thus, we propose a novel hybrid approach coupling the two algorithms in each iteration. This hybrid approach yielded very accurate estimates with minimal dependency on the initial guess using synthetic input data for which a ground truth parameter set exists.
When applied to measured data, the hybrid approach yielded the best fit, again with minimal variation. Using the proposed algorithm, a single run is sufficient to estimate the parameters. The degree of superiority over the other investigated algorithms in terms of accuracy and robustness depended on the type of current. In contrast to the non-hybrid approaches, the proposed method proved to be optimal for data of arbitrary signal to noise ratio.
The hybrid algorithm proposed in this work provides an important tool to integrate experimental data into computational models both accurately and robustly allowing to assess the often non-intuitive consequences of ion channel-level changes on higher levels of integration. Progress in biomedical engineering has improved the hardware available for diagnosis and treatment of cardiac arrhythmias. But although huge amounts of intracardiac electrograms EGMs can be acquired during electrophysiological examinations, there is still a lack of software aiding diagnosis.
The development of novel algorithms for the automated analysis of EGMs has proven difficult, due to the highly interdisciplinary nature of this task and hampered data access in clinical systems. Thus we developed a software platform, which allows rapid implementation of new algorithms, verification of their functionality and suitable visualization for discussion in the clinical environment.
Clinical data for analysis was exported from electroanatomical mapping systems. Both common and novel algorithms were implemented which address important clinical questions in diagnosis of different arrhythmias. It proved useful in discussions with clinicians due to its interactive and user-friendly design.
Time after export from the clinical mapping system to visualization is below 5min. KaPAVIE 2 is a powerful platform for the development of novel algorithms in the clinical environment. Simultaneous and interactive visualization of measured EGM data and the results of analysis will aid diagnosis and help understanding the underlying mechanisms of complex arrhythmias like atrial fibrillation. Whole-chamber mapping using a pole basket catheter BC has become a featured approach for the analysis of excitation patterns during atrial fibrillation. A flexible catheter design avoids perforation but may lead to spline bunching and influence coverage.
We aim to quantify the catheter deformation and endocardial coverage in clinical situations and study the effect of catheter size and electrode arrangement using an in silico basket model. Atrial coverage and spline separation were evaluated quantitatively in an ensemble of clinical measurements. A computational model of the BC was implemented including an algorithm to adapt its shape to the atrial anatomy. Two clinically relevant mapping positions in each atrium were assessed in both clinical and simulated data. The simulation environment allowed varying both BC size and electrode arrangement.
As spline bunching and insufficient coverage can hardly be avoided, this has to be taken into account for interpretation of excitation patterns and development of new panoramic mapping techniques. ECG imaging is an emerging technology for the reconstruction of cardiac electric activity from non-invasively measured body surface potential maps. In this case report, we present the first evaluation of transmurally imaged activation times against endocardially reconstructed isochrones for a case of sustained monomorphic ventricular tachycardia VT.
Computer models of the thorax and whole heart were produced from MR images. A recently published approach was applied to facilitate electrode localization in the catheter laboratory, which allows for the acquisition of body surface potential maps while performing non-contact mapping for the reconstruction of local activation times. ECG imaging was then realized using Tikhonov regularization with spatio-temporal smoothing as proposed by Huiskamp and Greensite and further with the spline-based approach by Erem et al.
Activation times were computed from transmurally reconstructed transmembrane voltages. The results showed good qualitative agreement between the non-invasively and invasively reconstructed activation times. Also, low amplitudes in the imaged transmembrane voltages were found to correlate with volumes of scar and grey zone in delayed gadolinium enhancement cardiac MR. The study underlines the ability of ECG imaging to produce activation times of ventricular electric activity-and to represent effects of scar tissue in the imaged transmembrane voltages.
One aim is to host an online repository that provides access to a wide spectrum of data, and the second aim is to provide a standard information format for the exchange of these diverse datasets. This web interface provides efficient, search, browsing, and retrieval of data from the repository. An aggregation of experimental, clinical and simulation data from various centers is being made available through the EDGAR project including experimental data from animal studies provided by the University of Utah USA , clinical data from multiple human subjects provided by the Charles University Hospital Czech Republic , and computer simulation data provided by the Karlsruhe Institute of Technology Germany.
Intracardiac electrograms are an indispensable part during diagnosis of supraventriculararrhythmias, but atrial activity AA can be obscured by ventricular far-fields VFF. Concepts based onstatistical independence like principal component analysis PCA cannot be applied for VFF removalduring atrial tachycardia with stable conduction. Analysis of clinical data confirmed these findings. Its concept and performance were benchmarked against PCA using simulated data and demonstratedon measured electrograms.
To evaluate two commonly used respiratory motion correction techniques for coronary magnetic resonance angiography MRA regarding their dependency on motion estimation accuracy and final image quality and to compare both methods to the respiratory gating approach used in clinical practice. Ten healthy volunteers were scanned using a non-Cartesian radial phase encoding acquisition. Respiratory motion was corrected for coronary MRA according to two motion correction techniques, image-based IMC and reconstruction-based RMC respiratory motion correction.
Both motion correction approaches were compared quantitatively and qualitatively against a reference standard navigator-based respiratory gating RG approach. Quantitative comparisons were performed regarding visible vessel length, vessel sharpness, and total acquisition time.
Two experts carried out a visual scoring of image quality. Additionally, numerical simulations were performed to evaluate the effect of motion estimation inaccuracy on RMC and IMC. RMC provides a similar image quality as the clinically used RG approach but almost halves the scan time and is independent of subjects' breathing patterns. Clinical validation of RMC is now desirable.
Catheter ablation has emerged as an effective treatment strategy for atrial fibrillation AF in recent years. During AF, complex fractionated atrial electrograms CFAE can be recorded and are known to be a potential target for ablation. Automatic algorithms have been developed to simplify CFAE detection, but they are often based on a single descriptor or a set of descriptors in combination with sharp decision classifiers.
However, these methods do not reflect the progressive transition between CFAE classes. The aim of this study was to develop an automatic classification algorithm, which combines the information of a complete set of descriptors and allows for progressive and transparent decisions. We designed a method to automatically analyze CFAE based on a set of descriptors representing various aspects, such as shape, amplitude and temporal characteristics.
A fuzzy decision tree FDT was trained and evaluated on predefined electrograms. In addition, a percentage of certainty is given for each electrogram to enable a comprehensive and transparent decision. The clinical efficacy in preventing the recurrence of atrial fibrillation AF is higher for amiodarone than for dronedarone. Moreover, pharmacotherapy with these drugs is less successful in patients with remodelled substrate induced by chronic AF cAF and patients suffering from familial AF. To date, the reasons for these phenomena are only incompletely understood.
We analyse the effects of the drugs in a computational model of atrial electrophysiology.
